Lately there has been controversy in the hospital engineering community concerning the use of isolated power systems and the 2012 changes in the National Fire Protection Association standard, NFPA 99.
Section 3.3.89 of NFPA99 2012 defines an Isolated Power System testing per NFPA99 as "A system comprising an isolation transformer or its equivalent, a line isolation monitor, and its ungrounded circuit conductors."
Section 3.3.9 of NFPA99 2012 defines a Line Isolation Monitor as "A test instrument designed to continually check the balanced and unbalanced impedance from each line of an isolated circuit to ground and equipped with a built-in test circuit to exercise the alarm without adding to the leakage current hazard." In an isolated power circuit, a ground fault would result in an alarm, but power would not be interrupted.
Section 3.3.184 of NFPA99 2012 defines a Wet Procedure Location as "The area in a patient care room where a procedure is performed that is normally subject to wet conditions while patients are present, including standing fluids on the floor or drenching of the work area, either of which condition is intimate to the patient or staff."
Section 188.8.131.52.1.2(C) of NFPA99 2012 addresses isolated power with regard to Critical Care Areas and states "Where used in locations such as critical care areas, isolated power panels shall be permitted in those locations."
Section 184.108.40.206.8 of NFPA99 2012 addresses Wet Procedure Locations.
Section 220.127.116.11.8.1 of NFPA99 2012 states "Wet procedure locations shall be provided with special protection against electric shock."
Section 18.104.22.168.8.4 of NFPA99 2012 states "Operating rooms shall be considered to be a wet procedure location, unless a risk assessment conducted by the health care governing body determines otherwise.
This is the most controversial section. A risk assessment by the health care governing body can in fact deem an operating room not to be a wet procedure location. This would be contingent on interpretation of the mopping of the floor which occurs between cases as "drenching", as defined in Section 3.3.89 above.
Section 22.214.171.124.8.6 of NFPA99 2012 states "The use of an isolated power system (IPS) shall be permitted as a protective means capable of limiting ground-fault current without power interruption. When installed, such a power system shall conform to the requirements of 126.96.36.199."
Section 188.8.131.52.8.7 of NFPA99 2012 states "Operating rooms defined as wet procedure locations shall be protected by either isolated power or ground fault circuit interrupters."
Section 184.108.40.206.9 of NFPA99 2012 addresses Isolated Power
Section 220.127.116.11.9.2 of NFPA99 2012 states "The system shall be permitted to be installed where it conforms to the performance requirements specified in 18.104.22.168.
Section 22.214.171.124.2.2 of NFPA99 2012 addresses Line Isolation Monitors
Section 126.96.36.199.3.2 of NFPA99 2012 states "The monitor shall be designed such that a green signal lamp, conspicuously visible in the area where the line isolation monitor is utilized, remains lighted when the system is adequately isolated from ground; and an adjacent red signal lamp and an audible warning signal (remote if desired) shall be energized when the total hazard current (consisting of possible resistive or capacitive leakage currents) from either isolated conductor to ground reaches a threshold value of 5.0 mA under normal line voltage conditions. The line isolation monitor shall not alarm for a fault hazard current of less than 3.7 mA.
This is interesting, as many of the Line Isolation Monitors still in use are older, often analog units that are set to alarm at only 2 mA. These units must be replaced immediately, as it is a violation of code to use them.
Section 188.8.131.52 of NFPA99 2012 addresses Performance Criteria and Testing for Isolated Power System testing per NFPA99.
Section 184.108.40.206.2 of NFPA99 2012 Line Isolation Monitor Tests states "The line isolation monitor (LIM) circuit shall be tested after installation, and prior to being placed in service, by successively grounding each line of the energized distribution system through a resistor whose value is 200 x V (ohms), where V equals measured line voltage. The visual and alarms shall be activated."
Section 220.127.116.11 of NFPA99 2012 addresses Maintenance and Testing of the Electrical System.
Section 18.104.22.168.4 of NFPA99 2012 states "The LIM circuit shall be tested at intervals of not more than 1 month by actuating the LIM test switch. For a LIM circuit with automated self-test and self-calibration capabilities, this test shall be performed at intervals of not more than 12 months. Actuation of the test switch shall activate both visual and audible alarm indicators.
Section 22.214.171.124 of NFPA99 2012 addresses Record Keeping.
Section 126.96.36.199.1.1 of NFPA99 2012 states "A record shall be maintained of the tests required by this chapter and associated repairs or modification.
Section 188.8.131.52.1.2 of NFPA99 2012 states "At a minimum, the record shall contain the date, the rooms or areas tested, and an indication of which items have met, or have failed to meet, the performance requirements of this chapter.
Section 6.3.4..2.2 of NFPA99 2012 Isolated Power System testing per NFPA99 (Where Installed) states "A permanent record shall be kept of the results of each of the tests.
